Hwam 3110m Woodburning Stove
The HWAM series combines modern design with a cosy atmosphere.
The design of this elliptical stove series originates in pure Scandinavian lines and simple forms that make the HWAM 3100 series more than just stoves. They are also attractive items of furniture that will adorn and warm any home. Hung on the wall, it has a discreet expression and is particularly easy to clean.
Options:
HWAM 3110 – Available on a pedestal, plinth or as wall mounted
HWAM 3110 – Available in grey or black steel
- Description
- Additional information
- Specifications
- Distance to combustible materials
- Diagram
Combustion Air System
No oxygen, no fire. It’s that simple. That is why a constant flow of air to the wood-burning stove is needed to create clean and effective combustion in your HWAM.
Convection
All HWAM and WIKING wood-burning stoves are convection stoves. This means that the wood-burning stove quickly emits heat after lighting.
3 way “Airwash”
Dancing flames are both fascinating and relaxing. Furthermore, flames are beautiful in all phases from the initial lighting to the burning of coals.
Comfort
A HWAM and WIKING wood-burning stove is designed for user-friendliness throughout the duration of its service lifetime.
Materials
Here at HWAM, we have been working with sheet iron for more than 45 years, and we know what advantages it provides for our customers.
Unique Door System
All HWAM & WIKING stoves have an easy and unique door closing system, which ensures that the door fits tightly
HWAM® Autopilot™
A wood-burning stove with HWAM® Autopilot ™ ensures excellent combustion – for the benefit of the environment and your firewood consumption – without any manual regulation of the air supply.
| Brand | Hwam |
|---|---|
| Stove Type | Pedestal, Wall Mounted, Freestanding |
| Fuel Type | Woodburning |
| Output to Room | 4.8KW |
| Colour & Finish | Black, Grey |
Specifications
Technical data
Energy efficiency class HWAM® Autopilot™ A
HWAM® Autopilot™ Yes
Efficiency (%) 79.0
Nominal heat output (kW) 4.8
Smoke outlet (Ø) 5″/6″
Chimney draught, recommended (Pa) 12.0
Weight (kg)
Steel cladding, c/m door9 8.0
Fresh air kit
Combustion air system can be mounted, back (Ø 100 mm) – additional purchase Yes
Combustion air system can be mounted, bottom (Ø 100 mm) – additional purchase Yes
Distance to combustible materials
Product measurements (cm)
Height 105.5
Width 47.7
Depth 41.3
Combustion chamber 33.0
Distance to combustible materials (cm)
Mantel piece 45.0
Floor 8.0
Distance to combustible materials Autopilot™ – insulated flue gas pipe (cm)
Behind 7.5
Side 22.0
Sides, in front of the stove 45.0
In front 105.0
Furnishing in front 105.0
Corner, 45° 10.0
Distance to combustible materials Autopilot™ – uninsulated flue gas pipe (cm)
Behind 12.5
Side 25.5
Sides, in front of the stove 45.0
In front 105.0
Furnishing in front 105.0
Corner, 45° 12.5
Diagram
